Waves System - Proxima 4040

Efficient

The Proxima 4040 media server features the most intuitive composer on the market. Connect to composer from your remote desktop and easily create a video projection with four video projectors. The soft-edge and sync frame offer exceptional rendering. The composer also includes a 15×15 warping grid to conform the video to a 3D structure. The NDI input allows the import of streams from other machines such as generative and interactive video engines. Perfect loops and fade transitions ensure broadcast continuity.

Integrated with other systems

The OSC API allows you to wake or put to sleep as well as launch pre-recorded sequences.

Rackable

The rack format of the Proxima 4040 media server is suitable for large installations.

Reliable and easy to setup

The Proxima 4040 media server is designed for 24/7 operation. It is robust to power outages. The Linux OS is mastered, updates are at the customer’s initiative.

Interfacing and connectivity

• 4  HDMI 2.1 video outputs, connections type-A  (up to 2xWUXGA@60Hz)
• 4 USB host:
  • 4 USB Host 3.2 Gen 2 Super Speed (10 Gbps), type-A receptacle
  • 2 USB Host 3.0 High Speed (5 Gbps), type-A receptacle
• 2×1 Gbps Ethernet on RJ45 connector with status LEDs (Network, Activity)
• Stereo audio output on a standard 3.5 mm (TRS) jack

Supported video outputs

• WUXGA (1920×1200), 50/60 Hz
• 1080p (1920 × 1080), 24/50/60 Hz
• 1080i (1920 × 1080), 50/60 Hz
• 720p (1280 × 720), 50/60 Hz
• Dynamic Range: HDR10 compatible

Supported media container formats

• Video :
  • .mp4 (MPEG-4)
  • .mkv (Matroska)
  • .mov (QuickTime)
• Image :
  • .jpg or .jpeg (Joint Photographic Experts Group) (ISO/IEC-10918)
  • .png (Portable Network Graphics)
  • .bmp (Bitmap)
• Audio :
  • .wav (WAV)
  • .mp3 (MPEG-Layer 3)
  • .ogg, .opus (OGG)
  • .m4a (MPEG-4 Audio)
  • .mka (Matroska)

Supported media codecs

• Video :
  • H.265 HEVC MP-10@L5.1 up to 4×WUXGA@60fps
  • VP9 Profile-2 up to 4xWUXGA@60fps
  • H.264 AVC HP@L5.1 up to 4xWUXGA@60fps
  • HAP, HAP Alpha, HAP Q
  • Apple ProRes
  • Motion JPEG
• Image :
  • JPEG (ISO/IEC-10918)
  • PNG
  • TIFF
• Audio :
  • MP3 : MPEG-1/2 Audio Layer III, mono / stereo, up to 48kHz, CBR (Constant Bit Rate) or VBR (Variable Bit Rate)
  • HE-AAC-LC : High-Efficiency Advanced Audio Coding, mono / stereo, up to 96kHz

Storage

• Hard drive: 500 Gb SSD NVME M.2
• RAM: 16 Gb-DIMM DDR5 5600 MHZ

Network

• Embedded web server:
  • Web administration :
    • Configuration
    • Control
  • OSC API & embedded UDP /OSC server for video control
  • Wake On Lan
  • Embedded TCP /IP server for server shutdown (Q1 ‘24)
  • Support input NDI stream
• Embedded NTP client for clock synch
• IPv4 and IPv6
• IPv4 : static or DHCP adress
• Embedded mDNS identification service (Zeroconf)

Built-in clock

• Timekeeping when the player is not powered: up to 2 months

Audio amplifiers

• Headphone output:
  • Maximum output power:
    • 2 × 15 mW for 32 Ω
    • 2 × 30 mW for 16 Ω
  • THD+N:
    • 0.014 % for 2 × 5 mW, 32 Ω, 1 kHz
    • 0.016 % for 2 × 10 mW, 32 Ω, 1 kHz
    • 0.022 % for 2 × 10 mW, 16 Ω, 1 kHz
    • 0.028 % for 2 × 20 mW, 16 Ω, 1 kHz

Power supply

• Power supply input:
  • Nominal voltage: 100-240 V AC – 50/60 Hz

Current Consumption

• Typical consumption in playback : 3 A

Thermal

• Operating ambient temperature: from 0 to +40 °C
• Storage temperature: from -40 to +85 °C

Dimensions

• Width: 440 mm
• Heigth: 176 mm
• Depth: 468 mm

Weight

• 13.9 Kgs
